DIN Standard NXF DN 15-1200 Class 150-2500 ASTM B574 B619 ALLOY C-4/W.NR 2.4610/UNS N06455/AWS 052 Blanks Figure 8 Blanks

Product Categories
NXF GROUP (New XiFei (SuZhou) Business Co.,Ltd)
Contact Now

DIN Standard NXF DN 15-1200 Class 150-2500 ASTM B574 B619 ALLOY C-4/W.NR 2.4610/UNS N06455/AWS 052 Blanks Figure 8 Blanks

Place of Origin : Jiangsu, China

Brand Name : NXF

Standard : ANSI, DIN, GB, ISO, JIS, Jpi, ASME

Product name : Blanks Figure 8 Blanks

Material : ALLOY C-4/W.NR 2.4610/UNS N06455/AWS 052

OD : DN 15-1200

Pressure : Class 150-2500

Application : Industry

Usage : Oil Gas Water Industrial

MOQ : 1 Piece

Brand : NXF

Packing : Wooden Box

Connection method : Weldng

MOQ : 10 pieces

Price : $5.00/pieces 10-49 pieces

Contact Now

Product Description
HASTELLOY C-4 alloy (UNS N06455) is the most (microstructurally) stable of the widely used nickel-chromium-molybdenum materials,which are well known for their resistance to many aggressive chemicals, in particular hydrochloric acid, sulfuric acid, and chlorides. This stability means that the alloy can be welded without fear of sensitization, i.e. the nucleation and growth of deleterious, second phase precipitates in the grain boundaries of the weld heat-affected zone (HAZ).Like other nickel alloys, it is ductile, easy to form and weld, and possesses exceptional resistance to stress corrosion cracking in chloride-bearing solutions (a form of degradation to which the austenitic stainless steels are prone). With its high chromium and molybdenum contents, it is able to withstand both oxidizing and non-oxidizing acids, and is resistant to pitting and crevice attack in the presence of chlorides and other halides.
Blanks Figure 8 Blanks Flange is a pipe fitting, which is mainly used for easy maintenance. You can know its specific shape by painting the upper part of the "8" black. It is half a blind plate and half an iron ring. It is often used in pipeline flanges that need to change the process. The main materials are carbon steel, stainless steel, and alloys. It can be selected according to the pipeline pressure level and pipeline medium. It is usually used on pipelines with larger diameters. Usually, one end of the flange is used to occupy the spacing to keep the pipeline unobstructed. When necessary, it is replaced with a blind plate of the same thickness at the other end to cut off the pipeline. Avoid forced expansion of the pipeline due to temporary replacement of other blind plates, affecting the entire system.
DIN Standard NXF DN 15-1200 Class 150-2500 ASTM B574 B619 ALLOY C-4/W.NR 2.4610/UNS N06455/AWS 052 Blanks Figure 8 Blanks
DIN Standard NXF DN 15-1200 Class 150-2500 ASTM B574 B619 ALLOY C-4/W.NR 2.4610/UNS N06455/AWS 052 Blanks Figure 8 Blanks
DIN Standard NXF DN 15-1200 Class 150-2500 ASTM B574 B619 ALLOY C-4/W.NR 2.4610/UNS N06455/AWS 052 Blanks Figure 8 Blanks
DIN Standard NXF DN 15-1200 Class 150-2500 ASTM B574 B619 ALLOY C-4/W.NR 2.4610/UNS N06455/AWS 052 Blanks Figure 8 Blanks
DIN Standard NXF DN 15-1200 Class 150-2500 ASTM B574 B619 ALLOY C-4/W.NR 2.4610/UNS N06455/AWS 052 Blanks Figure 8 Blanks
DIN Standard NXF DN 15-1200 Class 150-2500 ASTM B574 B619 ALLOY C-4/W.NR 2.4610/UNS N06455/AWS 052 Blanks Figure 8 Blanks
DIN Standard NXF DN 15-1200 Class 150-2500 ASTM B574 B619 ALLOY C-4/W.NR 2.4610/UNS N06455/AWS 052 Blanks Figure 8 Blanks
DIN Standard NXF DN 15-1200 Class 150-2500 ASTM B574 B619 ALLOY C-4/W.NR 2.4610/UNS N06455/AWS 052 Blanks Figure 8 Blanks
DIN Standard NXF DN 15-1200 Class 150-2500 ASTM B574 B619 ALLOY C-4/W.NR 2.4610/UNS N06455/AWS 052 Blanks Figure 8 Blanks
DIN Standard NXF DN 15-1200 Class 150-2500 ASTM B574 B619 ALLOY C-4/W.NR 2.4610/UNS N06455/AWS 052 Blanks Figure 8 Blanks
DIN Standard NXF DN 15-1200 Class 150-2500 ASTM B574 B619 ALLOY C-4/W.NR 2.4610/UNS N06455/AWS 052 Blanks Figure 8 Blanks
DIN Standard NXF DN 15-1200 Class 150-2500 ASTM B574 B619 ALLOY C-4/W.NR 2.4610/UNS N06455/AWS 052 Blanks Figure 8 Blanks
Specification
Shape
Equal
Head Code
Square
Customized support
OEM
Brand Name
NXF
Connection
Welding
Product name
Blanks Figure 8 Blanks
Material
ALLOY C-4/W.NR 2.4610/UNS N06455/AWS 052
OD
DN 15-1200
Pressure
Class 150-2500
Application
Industry
Usage
Oil Gas Water Industrial
MOQ
1 Piece
Packing
Wooden Box
Connection method
Weldng
Packing & Delivery
DIN Standard NXF DN 15-1200 Class 150-2500 ASTM B574 B619 ALLOY C-4/W.NR 2.4610/UNS N06455/AWS 052 Blanks Figure 8 Blanks
DIN Standard NXF DN 15-1200 Class 150-2500 ASTM B574 B619 ALLOY C-4/W.NR 2.4610/UNS N06455/AWS 052 Blanks Figure 8 Blanks
Company Profile
DIN Standard NXF DN 15-1200 Class 150-2500 ASTM B574 B619 ALLOY C-4/W.NR 2.4610/UNS N06455/AWS 052 Blanks Figure 8 Blanks
DIN Standard NXF DN 15-1200 Class 150-2500 ASTM B574 B619 ALLOY C-4/W.NR 2.4610/UNS N06455/AWS 052 Blanks Figure 8 Blanks
DIN Standard NXF DN 15-1200 Class 150-2500 ASTM B574 B619 ALLOY C-4/W.NR 2.4610/UNS N06455/AWS 052 Blanks Figure 8 Blanks
Other Products
DIN Standard NXF DN 15-1200 Class 150-2500 ASTM B574 B619 ALLOY C-4/W.NR 2.4610/UNS N06455/AWS 052 Blanks Figure 8 Blanks
Application Areas
DIN Standard NXF DN 15-1200 Class 150-2500 ASTM B574 B619 ALLOY C-4/W.NR 2.4610/UNS N06455/AWS 052 Blanks Figure 8 Blanks
Certifications
DIN Standard NXF DN 15-1200 Class 150-2500 ASTM B574 B619 ALLOY C-4/W.NR 2.4610/UNS N06455/AWS 052 Blanks Figure 8 Blanks
DIN Standard NXF DN 15-1200 Class 150-2500 ASTM B574 B619 ALLOY C-4/W.NR 2.4610/UNS N06455/AWS 052 Blanks Figure 8 Blanks
FAQ
1. who are we?
We are based in Jiangsu, China, start from 2021,sell to South Asia(30.00%),Eastern Asia(10.00%),Mid East(10.00%),Eastern Europe(10.00%),South America(10.00%),Domestic Market(5.00%),North America(5.00%),Northern Europe(5.00%),Central America(5.00%),Africa(5.00%),Southeast Asia(5.00%). There are total about 101-200 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Pipe,Flange,Steel plate,Pipe fittings,Alloy products

4. why should you buy from us not from other suppliers?
Our advantage:3S Service (Small Quantity/Short Time/Special Material) We have our own factories, quality can be controlled seriously. We Specialize in manufacturing about 21 years. We have professional testing department and testing equipment.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FCA；
Accepted Payment Currency:USD,EUR,CAD,HKD,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A;
Language Spoken:English,Chinese
